TUV Erp Certificated Split EVI heat pump with energy label A+

TUV Erp Certificated Split EVI heat pump with energy label A+
CategoriesEVI heat pump
AlbumView larger image
BrandREAL POWER
ModelRPEVI-10/12SH
FOB portGuangzhou port
Terms of PaymentT/T
Download DOC
Update Time2019-11-22
Detail Information
Features

1) Safe working at temp down to -25 degree
2) Adopting the most advanced low- temperature Enhanced Vapors Injection compressor technology.

3) It has been further optimized to enable heat pumps to efficiently produce water temperature up to 60 during cold winter time


EVI Theory of Operation

HOW DOES THE EVI COMPRESSOR WORK?





Technical data

Model RPEVI-10SH RPEVI-12SH
Heating capacity * KW 9.2 11.6
Heating power input * KW 2.5 3.2
Heating capacity ** KW 7.5 9.4
Heating power input ** KW 2.4 3.0
Heating capacity *** KW 5.3 6.4
Heating power input *** KW 2.4 2.9
COP* / 3.68 3.63
COP** / 3.13 3.13
COP*** / 2.21 2.21
Max. water temperature 60 60
Rated water temperature 55 55
Water flow m3/h 1.58 1.99
Water pressure drop Kpa 22 24
Water connections Inch 1 1
Built-in water pump  / wilo RS 25/8 wilo RS 25/8
Noise dB(A) 52 52
Compressor Brand Copeland (EVI) Copeland (EVI)
Quantity 1 1
Power supply / 220V/1PH/50Hz 220V/1PH/50Hz
Refrigerant / R407C R407C
Type of defrosting / Reverse circulation Reverse circulation
Net weight (outdoor unit) kg 75 85
Gross weight (outdoor unit) kg 90 100
Net dimensions (outdoor unit) mm 1110*460*850 1110*460*850
Packing dimensions (outdoor unit) mm 1175*530*1010 1175*530*1010
Net weight (indoor unit) kg 25 25
Gross weight (indoor unit) kg 27 27
Net dimensions (indoor unit) mm 500*220*840 500*220*840
Packing dimensions (indoor unit) mm 520*240*870 520*240*870
1. Unit working temperature : -25 to 43
2. *Test condition: ambient temp: 7/6, water inlet/outlet: 30/35
** Test condition: ambient temp: -2, water inlet/outlet: 30/35
*** Test condition: ambient temp: -20, water inlet/outlet: 30/35
